EVO11 Udendørs
Main image
Click to view image in fullscreen
![]()
Loading...
EVO11 downlight, with light quality that matches incandescent bulbs (CRI97), dimmable and with dip switches on the driver you get to choose between 5, 6, 8 or 10 watts. EVO11 is 360 degrees tiltable and dimmable with all common dimmers.
More Information
Downloads
Illustrations
References
Video
Colour
Outdoor White
Colour Temperature
3000
CRI (Ra)
Ra97
IP Rating
IP54
Download den ønskede fil ved at klikke på den.
Data p.t. ikke tilgængelig på web – kontakt os for yderligere information.
- Tiltable 0 - 30° / 360° rotatable
- Flicker free according to standard EN 62779
- Lumen: 80 - 85 lumen/watt
- 50.000 hours of life
- Dimmable
- Cut-out measure: 83 mm
- Built-in height: 57 mm
- Outer measure: 95 mm
- IP rate: IP 20/54, CLASS II, SDCM3
- Certification: / CE, RoHs
- Mounting: Directly in the insulation without the use of a spacer
- Tightness: Meets air tightness requirements in BBR
- Usable cables: Normal 70° kabler, although 90° cables if the cables are touching the lamp cylinder
- Ceiling thickness: Adjustable springs allow mounting in different ceiling thicknesses
- Forward looping: Spring clamps allow forward looping up to a 3Gx1.5 mm2 pole cable
